Cold Bend Test Apparatus of Bending Test at Low Temperature



We are professional Cold bend test aparatus manufacturers,Cold bend test apparatus,to determine the bending stability at low temperature of insulated cords and cables up to 12,5mm diameter in cold test chambers or freezers with mandrels to 50mm diameter, according to IEC60811-1-4 clause 8.1 figure 1,IEC 60598-2-21 clause 21.7.5 test 4 figure 2.

  • Item NO.:ZLT-SDJ1
  • Order(MOQ):1
  • Payment:T/T
  • Product Origin:China
  • Shipping Port:Guangzhou
  • Lead Time:20 days

Cold Bend Test Apparatus.

Cold Bend Test Apparatus of Bending Test at Low Temperature for Insulations.

Product details:Model ZLT-SDJ1



To determine the bending stability at low temperature of insulated cords and cables up to 12,5mm diameter in cold test chambers or freezers with mandrels to 50mm diameter, according to IEC60811-1-4 clause 8.1 figure 1,IEC 60598-2-21 clause 21.7.5 test 4 figure 2.

Standard outfit:

1 rigid horizontal structure

1 driving shaft, with bush to take up the mandrel, with journal for the actuating shaft,

1 transmission shaft,

1 sets of metal tubes, outlet diameter of 3-4-5-6-7-8-9-10-12-14-16 mm, for diameter of specimen 2,5~12,5 mm,

1 sets of metal tubes, diameter of 3-4-5-6-7-8-9-10-12-14-16 mm,

All stainless steel.
