IEC60227-6 Lift Polyvinyl Chloride Cables Flexibility Testing Machine



We are professional Lift cord flexibility test apparatus manufacturers,Lift cord flexing test apparatus,to determine the mechanical strength of lift cables,according to IEC60227-6 clause 4.4.1 and figure 3.

  • Item NO.:ZLT-QL4
  • Order(MOQ):1
  • Payment:T/T
  • Product Origin:China
  • Shipping Port:Guangzhou
  • Lead Time:20 days

Lift Cables Flexing Test Apparatus
IEC60227-6 Lift Polyvinyl Chloride Cables Flexibility Testing Machine
Product details: Model ZLT-QL4
To determine the mechanical strength of lift cables,according to IEC60227-6 clause 4.4.1 and figure 3.

Standard outfit:
Carriages mounted at the same height and move horizontally toward and away from each other in simple harmonic motion
Test times: Setting available
DC 12V supply to test voltage circuit for cable.
Distance between cable clamp: Maximum 1700±10mm, Minimum 760±10mm
Speed adjustable, available to uniform velocity or maximum acceleration of 4m/s2 and the test speed of 1500 complete cycles per hour, the distance of travel for each movement(up or down) shall be 650 mm.
Operated by PLC controlling system.Work station: 2 specimen testing

Power supply:A.C.220V 50Hz,other voltages and frequencies on request.
