Current-Carrying Abrasion Resistance Testing Apparatus.

Name: Current-Carrying Abrasion Resistance Testing Apparatus.
Brand: ZLTJC
Rating: 5.0 (5 reviews)

We are professional Current-Carrying Abrasion Resistance Testing Apparatus manufacturers.Current-Carrying Abrasion Resistance Testing Apparatus .in accordance with IEC60335-2-2 figure 101 clause 21.101.

Item NO.:ZLT-AR
Order(MOQ):1
Payment:T/T
Product Origin:China
Shipping Port:Guangzhou
Lead Time：20 days

Quantity:
Availability:





Inquire Add to Basket

Model:
ZLT-AR
Brand:
ZLTJC
Code:
ZLT-AR

Product Description

Current-Carrying Abrasion Resistance Testing Apparatus.

Product details:Model ZLT-AR

For testing the abrasion resistance of current-carrying hoses,according to IEC60335-2-2 figure 101 and clause 21.101.

Standard Outfit:

1 mass of 1 kg,is suspended from the other end of the hose,

1 motor with reduction and swiveling gear,for the crank rotates at 30 r/min resulting in the end of the hose moving horizontally backwards and forwards over a distance of 300 mm,

1 sets of roller,diameter 120mm,moves at speed of 0,1m/min,

1 abrasive cloth belt,is corundum grit size P100,

1 frame,for install the specimen,

1 power supply to specimen,

Power supply:AC220V 50Hz ,other voltages and frequencies on request,control by PLC.
